Name: Priority_Development_poly_scag

Display Field: Tier2

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: For Connect SoCal 2050, SCAG developed three categories of Priority Areas, which are High Priority, Medium Priority, and Low Priority. In order to determine what areas in the region fall within those categories, SCAG used eight components, or ingredients, which are measured at the Scenario Planning Zone (SPZ) geography. Data from PDA components can be used individually or combined in order to identify areas with a suitable set of travel and location characteristics. The eight components include: Walkable destinations – everyday destinations within 15 minutes of walking Intersection density – reflects improved walkability that may not be captured by a time threshold Bikeable destinations – everyday destinations within 15 minutes on bike Transit access – Regional jobs within 45 minutes during AM peak (2019 base year and 2050 plan year) Transit Priority Areas – Major transit stops + ½-mi buffer Mobility Hubs – at least two transportation modes that connect and interact with one another Bike Network – Regional existing and planned bike network (excluding Class III) Dedicated Transit Lanes – Regional dedicated transit lanes network For Connect SoCal 2050 growth visioning, all eight PDA components are mathematically combined with the objective of minimizing the per-capita Vehicle Miles Traveled (VMT) of residents in a PDA. Using a regression analysis, an ArcGIS suitability surface, and applied weights, each SPZ in the region receives a suitability score of 1-10 to reflect, in general, the degree to which residents in a PDA might be expected to have lower per-capita VMT. The higher the suitability score, the greater the impact of reducing VMT per-capita. Since the suitability score is a continuous measure based on regional data, it is well-suited for some planning applications such as preliminary regional growth visioning and VMT-based planning. However, other applications may need a specific, discrete area. Local jurisdictions are encouraged to use their own combination of eight PDA components, or a suitability score cutoff (e.g., the top 25 percent of SPZs in a jurisdiction) for their own strategies or programs. As a starting point, SCAG has also produced thresholds categorizing the SPZs based on their suitability scores. These thresholds categorize the data in to High Priority, Medium Priority, and Low Priority areas. Areas outside these thresholds are not considered PDAs.

Service Item Id: 3062cddedef648eabbb8ffdd71d9f277

Copyright Text: SCAG

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 272121.59609999973
YMin: 3609358.1361999996
XMax: 764148.6835000003
YMax: 3963607.8071999997
Spatial Reference: 26911  (26911)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [252, 250, 207, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• county_id ( type: esriFieldTypeInteger, alias: county_id )
• city_id ( type: esriFieldTypeInteger, alias: city_id )
• sub12 ( type: esriFieldTypeInteger, alias: sub12 )
• Tier2 ( type: esriFieldTypeString, alias: Tier2, length: 8 )
• fwy ( type: esriFieldTypeInteger, alias: fwy )
• ct2 ( type: esriFieldTypeString, alias: ct2, length: 15 )
• SPZID43 ( type: esriFieldTypeString, alias: SPZID43, length: 15 )
• LN_int_density ( type: esriFieldTypeDouble, alias: LN_int_density )
• LN_walk_access ( type: esriFieldTypeDouble, alias: LN_walk_access )
• LN_bike_access ( type: esriFieldTypeDouble, alias: LN_bike_access )
• LN_trans_access_pl ( type: esriFieldTypeDouble, alias: LN_trans_access_pl )
• ratio_tpa_area_pl ( type: esriFieldTypeDouble, alias: ratio_tpa_area_pl )
• ratio_mobilityH_area ( type: esriFieldTypeDouble, alias: ratio_mobilityH_area )
• bikelane_den_pl ( type: esriFieldTypeDouble, alias: bikelane_den_pl )
• Dtransit_den_pl ( type: esriFieldTypeDouble, alias: Dtransit_den_pl )
• suiability_score ( type: esriFieldTypeDouble, alias: suiability_score )
• ratio_conserved_area ( type: esriFieldTypeDouble, alias: ratio_conserved_area )
• PDA_Tier ( type: esriFieldTypeString, alias: PDA_Tier, length: 6 )
• YEAR ( type: esriFieldTypeInteger, alias: YEAR )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
