Name: MainLineRail_line_scag

Display Field: row_owner

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This dataset represents the mainline rail network within the SCAG region, derived from the North American Rail Network (NARN) dataset maintained by the Federal Railroad Administration (FRA) and part of USDOT’s National Transportation Atlas Database (NTAD). It includes key attributes such as right-of-way ownership, freight and passenger rail operators, and commuter rail operators. The dataset provides a snapshot of the mainline rail system for Connect SoCal 2024 (RTP/SCS 2024) to support regional goods movement and transportation planning, including LA28 preparations. Because rail networks change over time, it is subject to updates and should be used for planning purposes only, not for permitting or site-specific decisions. For the most recent NARN update, please refer to USDOT’s resource: https://geodata.bts.gov/datasets/e143f436d4774402aa8cca1e663b1d24_0/explore?location=34.235992%2C-108.308496%2C4.61

Service Item Id: c594c7e669884d76a37d6c05a9890c43

Copyright Text: U.S. Department of Transportation, Bureau of Transportation Statistics; SCAG

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 272159.24509999994
YMin: 3623879
XMax: 723438.5147000002
YMax: 3939805.5623000003
Spatial Reference: 26911  (26911)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [150, 113, 72, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• row_owner ( type: esriFieldTypeString, alias: ROW_OWNER, length: 5 )
• freight_op ( type: esriFieldTypeString, alias: FREIGHT_OP, length: 12 )
• pass_op ( type: esriFieldTypeString, alias: PASS_OP, length: 6 )
• pass_netwo ( type: esriFieldTypeString, alias: PASS_NETWO, length: 64 )
• comm_op ( type: esriFieldTypeString, alias: COMM_OP, length: 9 )
• comm_netwo ( type: esriFieldTypeString, alias: COMM_NETWO, length: 127 )
• year ( type: esriFieldTypeString, alias: Year, length: 4 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
